Now Comes with A 5 Year Warranty
Made for roads and city. Point A to point B just got a whole lot sweeter. Experience the wind in your face, air in your lungs, and what life on two wheels has to offer. Enhance your everyday adventure with the new CrossCore RC. Charge. Pedal. GO!
| SUGGESTED USE | Casual Pavement Adventure |
| COLORS |
|
| SIZE | 54cm (S), 57cm (M), 60cm (L) |
| MSRP | $3,099 |
| TOTAL WEIGHT | 52.2 (S), 52.4 (M), 52.6 (L) |
| MOTOR | PWSeries ST |
| CONTROL SWITCH AND MULTI-FUNCTION COMPUTER | Computer control functions include: (4) Power-level control switch, stop watch, distance units, power-level LED on/off, Bluetooth™ connectivity, cycling function display items, time adjustment, LED headlamp power on/off, 3-color LED power assist level light indicator Cycling function display include: speed, average speed, maximum speed, trip distance, odometer, cadence, battery capacity (%) |
| BATTERY | Yamaha Lithium Ion with charge-life indicator and self-diagnosis display Side-exiting dock station with anti-vibration mounting plate Weight 6.61lb 500Wh 36V 4-hour charge time |
| FRAME | Yamaha Hydroformed Aluminum Integrated battery Water bottle boss Tapered Headtube Internal shift/brake hose routing Rack/Fender compatible |
| FORK | SR Suntour NEX E25. 63mm Travel 2x100mm Thru-Axle |
| HEADSET | Integrated headset with 30mm headset spacers |
| STEM | Yamaha Alloy 4-bolt faceplate 31.8 diameter 80mm length (53cm, 55cm) 100mm length (58cm) |
| HANDLEBAR | Alloy flat bar zero degree rise 31.8mm diameter 640mm width |
| GRIPS/TAPE | Two-tone ergonomic locking |
| SEATPOST/SADDLE CLAMP | Alloy 30.9 x 295mm (S), 345mm (M L) with 2-bolt adjustable tilt saddle rail clamp |
| SEATPOST COLLAR | Alloy 2-bolt 35.0mm |
| SADDLE | Yamaha Urban Comfort Cro-Mo Rail |
| SHIFTERS | Shimano M2010 9-speed Gear selection window |
| FRONT DERAILLEUR | Shimano Sora (2 x 9) Braze-on |
| REAR DERAILLEUR | Shimano M3100 SGS |
| CRANKARM | Square taper 165mm (S) 170mm (M L) |
| CHAIN | KMC e11 118 links |
| CASSETTE | SHIMANO HG400 9-speed 11-13-15-17-20-23-26-30-36T |
| CHAINRING(S) | SAMOX 44t |
| BRAKES/ROTORS | Shimano MT200 front/rear |
| RIMS | 275” 32-Hole Dual Channel Welded Pin w/ Eyeleted Spoke |
| SPOKES | SUS304 14G |
| SPOKE NIPPLES | Brass |
| HUBS | Front: 12x100mm Quick-Release Thru-Axle (QRTA) Rear: 12x142mm QRTA with integrated speed sensor |
| TIRES/TUBES | CST C1996 27.5x2.0” |
| ACCESSORIES | Included Kickstand Yamaha battery charger Bell LED Headlight |
| WARRANTY | 3-Year on Frame, Drive Unit, Battery |
